Stainless Steel Die-Cast Parts Machining Services
Processing materials: 304/316L/410/420/17 – 4PH, etc.
Shape range: 500×400×300mm (customizable)
Wall thickness accuracy: minimum 0.8mm (complex parts) / 1.2mm (customizable)
Weight range: within 15kg (solid parts) / within 8kg (customizable)
Tolerance standard: GB/T 6414 CT4 – CT6 level (customizable)
Surface roughness: Ra≤1.6μm (polished surface) / Ra≤3.2μm (conventional surface) | customizable
High precision: Coordinate measuring machine detection accuracy of ±0.005mm, 100% full inspection for the first piece
Long lifespan: H13 mold lifespan ≥ 100,000 times, 20% higher than the industry average
Low defect rate: Air tightness test at 0.8MPa with 30 – second pressure holding and no leakage, defective rate ≤ 0.3%
